Haljas Hele Glass Single Standard 4-Person Outdoor Sauna House

Haljas Hele Glass Single Standard

Hele is an octagonal panoramic sauna that offers a social experience. It fits up to 4 people and is designed to enrich and amplify the environment. A circular seating around the heater creates an all-bare-honest atmosphere where everyone is equally included.

Hele Glass Single is Haljas' most prestigious sauna from their Hele Glass series, which has won the prestigious Red Dot award. Hele Single Standard interior charms with its simple but elegant sauna stage, which comfortably accommodates up to 4 people. The Hele Single Standard has been designed for use with a 12kW wood-fired sauna stove (sauna stove and chimney kit sold separately).

Unit is sold and shipped fully assembled.

What's included?

• Fully assembled unit
• Right bench
• Natural ventilation
• 4 adjustable legs
• 2-year warranty
• Product Manual

Features

• Fully Assembled

• Fits up to 4 people

• Red Dot Award Winner

• Designed for use with a 12 kW wood-fired sauna stove (sold separately)

• Bottom and Ceiling Panel: 60mm CLT panel

• Interior available in Aspen or Thermo-Alder

• Posts: Thermally modified pine/alder GL

• Roof: EPDM

• Slats: Factory-painted sheet metal

• Surround is tempered double-glazed mirror-effect glass

• LED IP-65 strips for interior and exterior lighting

• Designed and crafted in Estonia

• Dimensions: 7' 6-1/2"L x 7'-1/2"W x 8' 2-3/8"H

• 2-year warranty


Assembly

This unit ships fully assembled.

Surface preparations

• The soil underneath the sauna should be removed and replaced with a well-drained and load-bearing material (splinters, gravel, sand).
• Place 23 5/8" x 23 5/8" concrete tiles horizontally on the ground in accordance with the scheme of the sauna legs.
• Depending on the situation other foundations are allowed (concrete posts, screw pegs) or installing the sauna on a pre-existing surface (terrace, roof, stone pavement). It is important to ensure that the surface is load-bearing, there is enough space for ventilation underneath the sauna and there is water drainage. In addition, it is important to limit the growth of flora underneath and around the sauna in order to minimize any defects from moisture.
• Bring the power cable to the sauna in accordance with the heater manufacturer manual.

Sauna installation

• The sauna is lifted from stationary hooks on the roof.  Keep in mind the lifting capacity of the lift and the distance.
• After the lift, check that the connections between the hooks and the roof cover are hermetic. When necessary improve compression with a roof sealant.
• Make sure the legs are correctly placed on the surface.
• Level the sauna horizontally using the adjustable legs. Leave a 1% incline front to back to provide proper water drainage from the floor and ceiling.
• Place the stones into the heater in accordance with the heater's manufacturer manual.
• The sauna should be connected to the electricity network by a qualified electrician in accordance with the heater's manufacturer manual.

Maintenance

For maintenance, please refer to the Product Manual.
